Magnum Eight Piling Boat Lifts

Magnum Model "HD" features molded drive enclosures, complete guide pole package, elevated outside walkway, galvanized steel construction, 2/3 year warranty, stainless steel cables , worm gear driven winches, standard remote controls.

he 25K, 30K and 40K 'HD' models are designed to afford maximum hull support while keeping a low profile appearance.  This design allows for easy access to your vessel because of the open span between the drive units.  Standard to the 'HD' models are fully adjustable "I" beam bunking systems to gently cradle your boat.  Four worm gear driven winches positioned on top of eight pilings raise and lower the vessel.  An elevated outside walkway allows access to both sides of your vessel for easy cleaning and maintenance.  Remote controlled switches with upper and lower limits are a standard feature.

Capacity 25,000 / 30,000 / 40,000 lbs.
Cradle Travel 15' standard
Req. Power 220 volt / 40 amp
Piling Size Requirements Eight 12" diameter
Piling Height Above Deck 4' above the deck
Distance Between Piling Width Call
